DX80R

weight

8.38 ton

Bucket capacity (SAE HEAPED)

0.28

Engine power (SAE j1349, net)

40.7/2,000 kW/rpm

overview

Comfort



This standard-duty machine features a spacious operating area of a kind usually only found in medium and heavy-duty machines. The working controls in the cabin are ergonomically designed to ensure convenience and comfort for the operator.

Performance

The DX80R delivers the best performance with its powerful excavating force and high-tech hydraulic system, guaranteeing superior operational efficiency at any worksite. Excellent performance is its basic feature. Overall safety and convenience are also key factors when considering excellent performance.

Reliability

The reliability of a machine contributes to its overall lifetime operating costs. We use computer-assisted design techniques, and highly durable materials and structures which are tested under extreme conditions. Durability and longevity are our top priorities.


Maintenance

The most advanced technology has been integrated into the DX80R excavator to provide powerful performance and simple, easy maintenance, while providing the operator with convenient maintenance check points and maximizing the work efficiency of the DX80R.

Specifications

Machine series
DX80R
weight
8.38 ton
Bucket capacity (SAE HEAPED)
0.28 m3
Engine power (SAE j1349, net)
40.7/2,000 kW/rpm
Engine type
4TNV98-ZWDB8
Speed of movement
4.6/2.9 km/h
Maximum reach ground
6,915 mm
Maximum digging depth
4,180 mm
Maximum digging height
6,625 mm
Overall length
6,167 mm
Overall width
2,300 mm
Overall height
2,638 mm
